Y axis: 1490mm    Speed: 45m/min

A axis: 80mm      Speed: 45m/min

Z axis: 50mm      Speed: 45m/min

Drilling Unit

Vertical Spindle

7(X axis) +9(Y axis) including Ø35mm drill holder

Horizontal Spindle

2(Left)+2(Right) and 1(Front)+1(Back)

Motor power

1.5kw, 4000r/min

Router

Router type

Er32

Tool Shank Dia

Ø6,Ø8

Router power

2.2kw

Speed

12000r/min

Processing Size Range

Min work-piece width

50mm

Max work-piece width

850mm

Min work-piece length

250mm

Max work-piece thickness

50mm

Others

Working table height

950mm

Total power

14kw

Voltage

380V/50HZ

Air pressure

0.6-0.8Mpa

Weight

2300KG

Dimention

2800x2300x1700mm
